Home > Stainless Steel 316/316L Angles
Adam Stainless, located in Canberra, Australia, is a reputable manufacturer and supplier of top-notch Stainless Steel 316/316L Angles. Known for their commitment to quality and precision, Adam Stainless provides durable, corrosion-resistant angles that adhere to international standards. These angles are perfect for structural and architectural projects that demand exceptional strength and performance. With state-of-the-art manufacturing facilities and rigorous quality control measures, the company guarantees that each product offers outstanding reliability, weldability, and longevity. Adam Stainless proudly serves a variety of industries across Australia, delivering cost-effective, high-performance stainless steel solutions tailored to meet customer needs and the challenges of demanding operational environments.
Stainless Steel 316/316L Angles are primarily made up of chromium, nickel, and molybdenum, which give them remarkable corrosion resistance, particularly in chloride and marine settings. The Grade 316L variant features a lower carbon content, which improves weldability and reduces the risk of carbide precipitation. These alloys boast impressive mechanical properties, with a tensile strength of about 515 MPa, a yield strength of roughly 205 MPa, and good elongation and hardness. Their well-balanced composition ensures excellent toughness, resistance to oxidation, and long-lasting durability even under high-pressure and high-temperature conditions, making them ideal for demanding industrial applications.
| Standard | ASME, ASTM, EN, BS, GB, DIN, JIS, etc |
| Size | 3/4″ THRU 8″ |
| Thickness | 1/8″ thru 5/8″ |
| Type | Stuctural Steel Angle, Bars, Equal, Unequal, L, T, Hot Rolled |
| Grades | 304/304L/304H/310S/316/316L/316H/316TI/317/317L/321/321H/904L |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni |
|---|---|---|---|---|---|---|---|---|
| Stainless 304 | 0.08 max | 2 max | 0.75 max | 0.045 max | 0.030 max | 18 – 20 | – | 8 – 11 |
| Stainless 304L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 0.03 max | 18 – 20 | – | 8 – 13 |
| Stainless 316 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 16.00 – 18.00 | 2.00 – 3.00 | 11.00 – 14.00 |
| Stainless 316L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 1.0 max | 16.00 – 18.00 | 16.00 – 18.00 | 10.00 – 14.00 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
Contact us to get a quick quote for your requirement.
We conducts a strict quality test and obtains certifications to guarantee the best Stainless Steel 316/316L Angles in terms of strength, corrosion resistance, and accuracy. Each product batch is certified for compliance with international standards and offers clients full assurance in terms of reliability, performance, and conformity to industrial needs for a variety of uses.
Stainless Steel 316/316L angles are L-shaped structural components known for their excellent corrosion resistance, strength, and durability. They are used in marine, chemical, and high-temperature applications for support and reinforcement.
Stainless Steel 316/316L equal angles have two legs of the same length, forming a 90-degree angle. They offer high strength and corrosion resistance, ideal for structural support in demanding environments.
Stainless Steel 316/316L unequal angles have legs of different lengths, creating a 90-degree angle. They provide versatile support and reinforcement in construction and industrial applications, offering high strength and corrosion resistance.
Stainless Steel 316/316L L angles are L-shaped structural components offering high strength, durability, and superior corrosion resistance. They are used for framing and support in marine, chemical, and high-temperature environments.
SS 316/316L T-bar angles are stainless steel sections with a T-shaped profile, providing robust support and stability. They are ideal for structural and framework applications, offering high strength and corrosion resistance.
Stainless Steel 316/316L corner angles are L-shaped sections designed for reinforcing and joining corners. They offer high strength, durability, and excellent corrosion resistance, making them suitable for construction and architectural applications.
Thanks to their strength, durability, and resistance to corrosive environments, Stainless Steel 316/316L Angles are widely utilized across various industries. They are particularly suited for chemical processing, food and beverage production, marine construction, and the pharmaceutical sector. Additionally, these angles find applications in architectural structures, heat exchangers, storage tanks, and fabrication projects that require superior formability and toughness. Their hygienic properties also make them a great choice for cleanroom and sanitary applications. The combination of mechanical strength and corrosion resistance ensures they perform exceptionally well in challenging environments.
